API Documentation¶
LCD display drivers.
Upgrading¶
Warning
Version 2.0.0 was released on 2 June 2019: this came with the removal of the
luma.lcd.aux.backlight
class. The equivalent functionality has now
been subsumed into the device classes that have a backlight capability.
luma.lcd.device
¶
Collection of serial interfaces to LCD devices.
-
class
luma.lcd.device.
hd44780
(serial_interface=None, width=16, height=2, undefined='_', selected_font=0, exec_time=1e-06, framebuffer=None, **kwargs)[source]¶ Bases:
luma.lcd.device.backlit_device
,luma.core.device.parallel_device
,luma.core.virtual.character
,luma.lcd.device.__framebuffer_mixin
Driver for a HD44780 style LCD display. This class provides a
text
property which can be used to set and get a text value, which will be rendered to the display’s screen using the display’s built-in font.- Parameters
serial_interface – The serial interface (usually a
luma.core.interface.serial.parallel
instance) to delegate sending data and commands through.width (int) – The number of characters that can be displayed on a line.
height (int) – The number of lines the display supports.
undefined (str) – character to use if a requested character is not in the font tables
selected_font (int or str) – the font table appropriate for the model of display you are using. The hd44780 normally comes in a version with font A00 (ENGLISH_JAPANESE) or A02 (ENGLISH_EUROPEAN). You can provide either the name (‘A00’ or ‘A02’) or the number (0 for ‘A00’, 1 for ‘A02’) for the font your display contains.
exec_time (float) – Time in seconds to wait for a command to complete. Default is 50 μs (1e-6 * 50) which typically is long enough for commands to finish. If your display is not working correctly, you may want to try increasing the exec_time delay.
gpio_LIGHT (int) – The GPIO pin to use for the backlight if it is controlled by one of the GPIO pins.
active_low (bool) – Set to true if backlight is active low (default), false otherwise.
pwm_frequency (float) – Use PWM for backlight brightness control with the specified frequency when provided.
framebuffer (luma.core.framebuffer.framebuffer) – Framebuffering strategy, currently instances of
diff_to_previous()
orfull_frame()
are only supported.
To place text on the display, simply assign the text to the
text
instance variable:p = parallel(RS=7, E=8, PINS=[25,24,23,18]) my_display = hd44780(p, selected_font='A00') my_display.text = 'HD44780 Display\nFont A00 Eng/Jap'
For more details on how to use the ‘text’ interface see
luma.core.virtual.character
- ..note:
This driver currently only supports the hd44780 5x8 display mode.
New in version 2.5.0.
-
capabilities
(width, height, rotate, mode='1')¶ Assigns attributes such as
width
,height
,size
andbounding_box
correctly oriented from the supplied parameters.- Parameters
width (int) – The device width.
height (int) – The device height.
rotate (int) – An integer value of 0 (default), 1, 2 or 3 only, where 0 is no rotation, 1 is rotate 90° clockwise, 2 is 180° rotation and 3 represents 270° rotation.
mode (str) – The supported color model, one of
"1"
,"RGB"
or"RGBA"
only.
-
cleanup
()¶ Attempt to reset the device & switching it off prior to exiting the python process.
-
clear
()¶ Initializes the device memory with an empty (blank) image.
-
command
(*cmd, exec_time=None, only_low_bits=False)¶ Sends a command or sequence of commands through to the serial interface. If operating in four bit mode, expands each command from one byte values (8 bits) to two nibble values (4 bits each)
- Parameters
cmd (int) – A spread of commands.
exec_time (float) – Amount of time to wait for the command to finish execution. If not provided, the device default will be used instead
only_low_bits (bool) – If
True
, only the lowest four bits of the command will be sent. This is necessary on some devices during initialization
-
data
(data)¶ Sends a sequence of bytes through to the serial interface. If operating in four bit mode, expands each byte from a single value (8 bits) to two nibble values (4 bits each)
- Parameters
data (list) – a sequence of bytes to send to the display
-
display
(image)[source]¶ Takes a 1-bit
PIL.Image
and converts it to text data by reversing from glyphs from the image back to the correct value from the displays font table.- Parameters
image (
PIL.Image.Image
) – the image to place on the display
If needed, it will create custom characters if a glyph is not found within the font table.
-
get_font
(ft)[source]¶ Return one of the devices built-in fonts as a
PIL.ImageFont
object
-
hide
()¶ Switches the display mode OFF, putting the device in low-power sleep mode.
-
init_framebuffer
(framebuffer, default_num_segments)¶
-
preprocess
(image)¶ Provides a preprocessing facility (which may be overridden) whereby the supplied image is rotated according to the device’s rotate capability. If this method is overridden, it is important to call the
super
method.- Parameters
image (PIL.Image.Image) – An image to pre-process.
- Returns
A new processed image.
- Return type
-
show
()¶ Sets the display mode ON, waking the device out of a prior low-power sleep mode.
-
property
text
¶ Returns the current state of the text buffer. This may not reflect accurately what is displayed on the device if the font does not have a symbol for a requested text value.
-
class
luma.lcd.device.
ht1621
(gpio=None, width=6, rotate=0, WR=11, DAT=10, CS=8, **kwargs)[source]¶ Bases:
luma.lcd.device.backlit_device
Serial interface to a seven segment HT1621 monochrome LCD display.
On creation, an initialization sequence is pumped to the display to properly configure it. Further control commands can then be called to affect the brightness and other settings.
- Parameters
gpio – The GPIO library to use (usually RPi.GPIO) to delegate sending data and commands through.
width (int) – The number of 7 segment characters laid out horizontally.
rotate (int) – An integer value of 0 (default), 1, 2 or 3 only, where 0 is no rotation, 1 is rotate 90° clockwise, 2 is 180° rotation and 3 represents 270° rotation.
WR (int) – The write (SPI clock) pin to connect to, default BCM 11.
DAT (int) – The data pin to connect to, default BCM 10.
CS (int) – The chip select pin to connect to, default BCM 8.
New in version 0.4.0.
-
capabilities
(width, height, rotate, mode='1')¶ Assigns attributes such as
width
,height
,size
andbounding_box
correctly oriented from the supplied parameters.- Parameters
width (int) – The device width.
height (int) – The device height.
rotate (int) – An integer value of 0 (default), 1, 2 or 3 only, where 0 is no rotation, 1 is rotate 90° clockwise, 2 is 180° rotation and 3 represents 270° rotation.
mode (str) – The supported color model, one of
"1"
,"RGB"
or"RGBA"
only.
-
cleanup
()[source]¶ Attempt to reset the device & switching it off prior to exiting the python process.
-
clear
()¶ Initializes the device memory with an empty (blank) image.
-
command
(cmd)[source]¶ Sends a command or sequence of commands through to the delegated serial interface.
-
contrast
(level)¶ Switches the display contrast to the desired level, in the range 0-255. Note that setting the level to a low (or zero) value will not necessarily dim the display to nearly off. In other words, this method is NOT suitable for fade-in/out animation.
- Parameters
level (int) – Desired contrast level in the range of 0-255.
-
data
(data)[source]¶ Sends a data byte or sequence of data bytes through to the delegated serial interface.
-
hide
()¶ Switches the display mode OFF, putting the device in low-power sleep mode.
-
preprocess
(image)¶ Provides a preprocessing facility (which may be overridden) whereby the supplied image is rotated according to the device’s rotate capability. If this method is overridden, it is important to call the
super
method.- Parameters
image (PIL.Image.Image) – An image to pre-process.
- Returns
A new processed image.
- Return type
-
show
()¶ Sets the display mode ON, waking the device out of a prior low-power sleep mode.
-
class
luma.lcd.device.
ili9341
(serial_interface=None, width=320, height=240, rotate=0, framebuffer=None, h_offset=0, v_offset=0, bgr=False, **kwargs)[source]¶ Bases:
luma.lcd.device.backlit_device
,luma.lcd.device.__framebuffer_mixin
Serial interface to a 262k color (6-6-6 RGB) ILI9341 LCD display.
On creation, an initialization sequence is pumped to the display to properly configure it. Further control commands can then be called to affect the brightness and other settings.
- Parameters
serial_interface – the serial interface (usually a
luma.core.interface.serial.spi
instance) to delegate sending data and commands through.width (int) – The number of pixels laid out horizontally.
height (int) – The number of pixels laid out vertically.
rotate (int) – An integer value of 0 (default), 1, 2 or 3 only, where 0 is no rotation, 1 is rotate 90° clockwise, 2 is 180° rotation and 3 represents 270° rotation.
framebuffer (luma.core.framebuffer.framebuffer) – Framebuffering strategy, currently instances of
diff_to_previous()
orfull_frame()
are only supported.bgr (bool) – Set to
True
if device pixels are BGR order (rather than RGB).h_offset (int) – Horizontal offset (in pixels) of screen to device memory (default: 0).
v_offset (int) – Vertical offset (in pixels) of screen to device memory (default: 0).
New in version 2.2.0.
-
capabilities
(width, height, rotate, mode='1')¶ Assigns attributes such as
width
,height
,size
andbounding_box
correctly oriented from the supplied parameters.- Parameters
width (int) – The device width.
height (int) – The device height.
rotate (int) – An integer value of 0 (default), 1, 2 or 3 only, where 0 is no rotation, 1 is rotate 90° clockwise, 2 is 180° rotation and 3 represents 270° rotation.
mode (str) – The supported color model, one of
"1"
,"RGB"
or"RGBA"
only.
-
cleanup
()¶ Attempt to reset the device & switching it off prior to exiting the python process.
-
clear
()¶ Initializes the device memory with an empty (blank) image.
-
command
(cmd, *args)[source]¶ Sends a command and an (optional) sequence of arguments through to the delegated serial interface. Note that the arguments are passed through as data.
-
contrast
(level)[source]¶ NOT SUPPORTED
- Parameters
level (int) – Desired contrast level in the range of 0-255.
-
data
(data)¶ Sends a data byte or sequence of data bytes through to the delegated serial interface.
-
display
(image)[source]¶ Renders a 24-bit RGB image to the ILI9341 LCD display. The 8-bit RGB values are passed directly to the devices internal storage, but only the 6 most-significant bits are used by the display.
- Parameters
image (PIL.Image.Image) – The image to render.
-
hide
()¶ Switches the display mode OFF, putting the device in low-power sleep mode.
-
init_framebuffer
(framebuffer, default_num_segments)¶
-
preprocess
(image)¶ Provides a preprocessing facility (which may be overridden) whereby the supplied image is rotated according to the device’s rotate capability. If this method is overridden, it is important to call the
super
method.- Parameters
image (PIL.Image.Image) – An image to pre-process.
- Returns
A new processed image.
- Return type
-
show
()¶ Sets the display mode ON, waking the device out of a prior low-power sleep mode.
-
class
luma.lcd.device.
ili9486
(serial_interface=None, width=320, height=480, rotate=0, framebuffer=None, h_offset=0, v_offset=0, bgr=False, **kwargs)[source]¶ Bases:
luma.lcd.device.backlit_device
,luma.lcd.device.__framebuffer_mixin
Serial interface to a 262k color (6-6-6 RGB) ILI9486 LCD display.
On creation, an initialization sequence is pumped to the display to properly configure it. Further control commands can then be called to affect the brightness (if implemented) and other settings.
Note that the ILI9486 display used for development – a Waveshare 3.5-inch IPS LCD(B) – used a portrait orientation. Images were rendered correctly only when specifying that height was 480 pixels and the width was 320.
- Parameters
serial_interface – the serial interface (usually a
luma.core.interface.serial.spi
instance) to delegate sending data and commands through.width (int) – The number of pixels laid out horizontally.
height (int) – The number of pixels laid out vertically.
rotate (int) – An integer value of 0 (default), 1, 2 or 3 only, where 0 is no rotation, 1 is rotate 90° clockwise, 2 is 180° rotation and 3 represents 270° rotation.
framebuffer (luma.core.framebuffer.framebuffer) – Framebuffering strategy, currently instances of
diff_to_previous()
orfull_frame()
are only supported.bgr (bool) – Set to
True
if device pixels are BGR order (rather than RGB).h_offset (int) – Horizontal offset (in pixels) of screen to device memory (default: 0).
v_offset (int) – Vertical offset (in pixels) of screen to device memory (default: 0).
New in version 2.8.0.
-
capabilities
(width, height, rotate, mode='1')¶ Assigns attributes such as
width
,height
,size
andbounding_box
correctly oriented from the supplied parameters.- Parameters
width (int) – The device width.
height (int) – The device height.
rotate (int) – An integer value of 0 (default), 1, 2 or 3 only, where 0 is no rotation, 1 is rotate 90° clockwise, 2 is 180° rotation and 3 represents 270° rotation.
mode (str) – The supported color model, one of
"1"
,"RGB"
or"RGBA"
only.
-
cleanup
()¶ Attempt to reset the device & switching it off prior to exiting the python process.
-
clear
()¶ Initializes the device memory with an empty (blank) image.
-
command
(cmd, *args)[source]¶ Sends a command and an (optional) sequence of arguments through to the delegated serial interface. Note that the arguments are passed through as data.
-
contrast
(level)[source]¶ NOT SUPPORTED
- Parameters
level (int) – Desired contrast level in the range of 0-255.
-
data
(data)¶ Sends a data byte or sequence of data bytes through to the delegated serial interface.
-
display
(image)[source]¶ Renders a 24-bit RGB image to the ILI9486 LCD display. The 8-bit RGB values are passed directly to the devices internal storage, but only the 6 most-significant bits are used by the display.
- Parameters
image (PIL.Image.Image) – The image to render.
-
hide
()¶ Switches the display mode OFF, putting the device in low-power sleep mode.
-
init_framebuffer
(framebuffer, default_num_segments)¶
-
preprocess
(image)¶ Provides a preprocessing facility (which may be overridden) whereby the supplied image is rotated according to the device’s rotate capability. If this method is overridden, it is important to call the
super
method.- Parameters
image (PIL.Image.Image) – An image to pre-process.
- Returns
A new processed image.
- Return type
-
show
()¶ Sets the display mode ON, waking the device out of a prior low-power sleep mode.
-
class
luma.lcd.device.
pcd8544
(serial_interface=None, rotate=0, **kwargs)[source]¶ Bases:
luma.lcd.device.backlit_device
Serial interface to a monochrome PCD8544 LCD display.
On creation, an initialization sequence is pumped to the display to properly configure it. Further control commands can then be called to affect the brightness and other settings.
- Parameters
serial_interface – The serial interface (usually a
luma.core.interface.serial.spi
instance) to delegate sending data and commands through.rotate (int) – An integer value of 0 (default), 1, 2 or 3 only, where 0 is no rotation, 1 is rotate 90° clockwise, 2 is 180° rotation and 3 represents 270° rotation.
-
capabilities
(width, height, rotate, mode='1')¶ Assigns attributes such as
width
,height
,size
andbounding_box
correctly oriented from the supplied parameters.- Parameters
width (int) – The device width.
height (int) – The device height.
rotate (int) – An integer value of 0 (default), 1, 2 or 3 only, where 0 is no rotation, 1 is rotate 90° clockwise, 2 is 180° rotation and 3 represents 270° rotation.
mode (str) – The supported color model, one of
"1"
,"RGB"
or"RGBA"
only.
-
cleanup
()¶ Attempt to reset the device & switching it off prior to exiting the python process.
-
clear
()¶ Initializes the device memory with an empty (blank) image.
-
command
(*cmd)¶ Sends a command or sequence of commands through to the delegated serial interface.
-
data
(data)¶ Sends a data byte or sequence of data bytes through to the delegated serial interface.
-
hide
()¶ Switches the display mode OFF, putting the device in low-power sleep mode.
-
preprocess
(image)¶ Provides a preprocessing facility (which may be overridden) whereby the supplied image is rotated according to the device’s rotate capability. If this method is overridden, it is important to call the
super
method.- Parameters
image (PIL.Image.Image) – An image to pre-process.
- Returns
A new processed image.
- Return type
-
show
()¶ Sets the display mode ON, waking the device out of a prior low-power sleep mode.
-
class
luma.lcd.device.
st7567
(serial_interface=None, rotate=0, **kwargs)[source]¶ Bases:
luma.lcd.device.backlit_device
Serial interface to a monochrome ST7567 128x64 pixel LCD display.
On creation, an initialization sequence is pumped to the display to properly configure it. Further control commands can then be called to affect the brightness and other settings.
- Parameters
serial_interface – The serial interface (usually a
luma.core.interface.serial.spi
instance) to delegate sending data and commands through.rotate (int) – An integer value of 0 (default), 1, 2 or 3 only, where 0 is no rotation, 1 is rotate 90° clockwise, 2 is 180° rotation and 3 represents 270° rotation.
New in version 1.1.0.
-
capabilities
(width, height, rotate, mode='1')¶ Assigns attributes such as
width
,height
,size
andbounding_box
correctly oriented from the supplied parameters.- Parameters
width (int) – The device width.
height (int) – The device height.
rotate (int) – An integer value of 0 (default), 1, 2 or 3 only, where 0 is no rotation, 1 is rotate 90° clockwise, 2 is 180° rotation and 3 represents 270° rotation.
mode (str) – The supported color model, one of
"1"
,"RGB"
or"RGBA"
only.
-
cleanup
()¶ Attempt to reset the device & switching it off prior to exiting the python process.
-
clear
()¶ Initializes the device memory with an empty (blank) image.
-
command
(*cmd)¶ Sends a command or sequence of commands through to the delegated serial interface.
-
data
(data)¶ Sends a data byte or sequence of data bytes through to the delegated serial interface.
-
hide
()¶ Switches the display mode OFF, putting the device in low-power sleep mode.
-
preprocess
(image)¶ Provides a preprocessing facility (which may be overridden) whereby the supplied image is rotated according to the device’s rotate capability. If this method is overridden, it is important to call the
super
method.- Parameters
image (PIL.Image.Image) – An image to pre-process.
- Returns
A new processed image.
- Return type
-
show
()¶ Sets the display mode ON, waking the device out of a prior low-power sleep mode.
-
class
luma.lcd.device.
st7735
(serial_interface=None, width=160, height=128, rotate=0, framebuffer=None, h_offset=0, v_offset=0, bgr=False, inverse=False, **kwargs)[source]¶ Bases:
luma.lcd.device.backlit_device
,luma.lcd.device.__framebuffer_mixin
Serial interface to a 262K color (6-6-6 RGB) ST7735 LCD display.
On creation, an initialization sequence is pumped to the display to properly configure it. Further control commands can then be called to affect the brightness and other settings.
- Parameters
serial_interface – the serial interface (usually a
luma.core.interface.serial.spi
instance) to delegate sending data and commands through.width (int) – The number of pixels laid out horizontally.
height (int) – The number of pixels laid out vertically.
rotate (int) – An integer value of 0 (default), 1, 2 or 3 only, where 0 is no rotation, 1 is rotate 90° clockwise, 2 is 180° rotation and 3 represents 270° rotation.
framebuffer (luma.core.framebuffer.framebuffer) – Framebuffering strategy, currently instances of
diff_to_previous()
orfull_frame()
are only supported.bgr (bool) – Set to
True
if device pixels are BGR order (rather than RGB).inverse (bool) – Set to
True
if device pixels are inversed.h_offset (int) – Horizontal offset (in pixels) of screen to device memory (default: 0).
v_offset (int) – Vertical offset (in pixels) of screen to device memory (default: 0).
New in version 0.3.0.
-
capabilities
(width, height, rotate, mode='1')¶ Assigns attributes such as
width
,height
,size
andbounding_box
correctly oriented from the supplied parameters.- Parameters
width (int) – The device width.
height (int) – The device height.
rotate (int) – An integer value of 0 (default), 1, 2 or 3 only, where 0 is no rotation, 1 is rotate 90° clockwise, 2 is 180° rotation and 3 represents 270° rotation.
mode (str) – The supported color model, one of
"1"
,"RGB"
or"RGBA"
only.
-
cleanup
()¶ Attempt to reset the device & switching it off prior to exiting the python process.
-
clear
()¶ Initializes the device memory with an empty (blank) image.
-
command
(cmd, *args)[source]¶ Sends a command and an (optional) sequence of arguments through to the delegated serial interface. Note that the arguments are passed through as data.
-
contrast
(level)[source]¶ NOT SUPPORTED
- Parameters
level (int) – Desired contrast level in the range of 0-255.
-
data
(data)¶ Sends a data byte or sequence of data bytes through to the delegated serial interface.
-
display
(image)[source]¶ Renders a 24-bit RGB image to the ST7735 LCD display. The 8-bit RGB values are passed directly to the devices internal storage, but only the 6 most-significant bits are used by the display.
- Parameters
image (PIL.Image.Image) – The image to render.
-
hide
()¶ Switches the display mode OFF, putting the device in low-power sleep mode.
-
init_framebuffer
(framebuffer, default_num_segments)¶
-
preprocess
(image)¶ Provides a preprocessing facility (which may be overridden) whereby the supplied image is rotated according to the device’s rotate capability. If this method is overridden, it is important to call the
super
method.- Parameters
image (PIL.Image.Image) – An image to pre-process.
- Returns
A new processed image.
- Return type
-
show
()¶ Sets the display mode ON, waking the device out of a prior low-power sleep mode.
-
class
luma.lcd.device.
st7789
(serial_interface=None, rotate=0, **kwargs)[source]¶ Bases:
luma.lcd.device.backlit_device
Serial interface to a colour ST7789 240x240 pixel LCD display.
New in version 2.9.0.
-
capabilities
(width, height, rotate, mode='1')¶ Assigns attributes such as
width
,height
,size
andbounding_box
correctly oriented from the supplied parameters.- Parameters
width (int) – The device width.
height (int) – The device height.
rotate (int) – An integer value of 0 (default), 1, 2 or 3 only, where 0 is no rotation, 1 is rotate 90° clockwise, 2 is 180° rotation and 3 represents 270° rotation.
mode (str) – The supported color model, one of
"1"
,"RGB"
or"RGBA"
only.
-
cleanup
()¶ Attempt to reset the device & switching it off prior to exiting the python process.
-
clear
()¶ Initializes the device memory with an empty (blank) image.
-
command
(*cmd)¶ Sends a command or sequence of commands through to the delegated serial interface.
-
contrast
(level)[source]¶ NOT SUPPORTED
- Parameters
level (int) – Desired contrast level in the range of 0-255.
-
data
(data)¶ Sends a data byte or sequence of data bytes through to the delegated serial interface.
-
display
(image)[source]¶ Should be overridden in sub-classed implementations.
- Parameters
image (PIL.Image.Image) – An image to display.
- Raises
-
hide
()¶ Switches the display mode OFF, putting the device in low-power sleep mode.
-
preprocess
(image)¶ Provides a preprocessing facility (which may be overridden) whereby the supplied image is rotated according to the device’s rotate capability. If this method is overridden, it is important to call the
super
method.- Parameters
image (PIL.Image.Image) – An image to pre-process.
- Returns
A new processed image.
- Return type
-
show
()¶ Sets the display mode ON, waking the device out of a prior low-power sleep mode.
-
-
class
luma.lcd.device.
uc1701x
(serial_interface=None, rotate=0, **kwargs)[source]¶ Bases:
luma.lcd.device.backlit_device
Serial interface to a monochrome UC1701X LCD display.
On creation, an initialization sequence is pumped to the display to properly configure it. Further control commands can then be called to affect the brightness and other settings.
- Parameters
serial_interface – The serial interface (usually a
luma.core.interface.serial.spi
instance) to delegate sending data and commands through.rotate (int) – An integer value of 0 (default), 1, 2 or 3 only, where 0 is no rotation, 1 is rotate 90° clockwise, 2 is 180° rotation and 3 represents 270° rotation.
New in version 0.5.0.
-
capabilities
(width, height, rotate, mode='1')¶ Assigns attributes such as
width
,height
,size
andbounding_box
correctly oriented from the supplied parameters.- Parameters
width (int) – The device width.
height (int) – The device height.
rotate (int) – An integer value of 0 (default), 1, 2 or 3 only, where 0 is no rotation, 1 is rotate 90° clockwise, 2 is 180° rotation and 3 represents 270° rotation.
mode (str) – The supported color model, one of
"1"
,"RGB"
or"RGBA"
only.
-
cleanup
()¶ Attempt to reset the device & switching it off prior to exiting the python process.
-
clear
()¶ Initializes the device memory with an empty (blank) image.
-
command
(*cmd)¶ Sends a command or sequence of commands through to the delegated serial interface.
-
data
(data)¶ Sends a data byte or sequence of data bytes through to the delegated serial interface.
-
hide
()¶ Switches the display mode OFF, putting the device in low-power sleep mode.
-
preprocess
(image)¶ Provides a preprocessing facility (which may be overridden) whereby the supplied image is rotated according to the device’s rotate capability. If this method is overridden, it is important to call the
super
method.- Parameters
image (PIL.Image.Image) – An image to pre-process.
- Returns
A new processed image.
- Return type
-
show
()¶ Sets the display mode ON, waking the device out of a prior low-power sleep mode.
